Part No : XY126V-5.0
No of Poles : 2P,3P-24P
Pitch (mm) : 5
Rating : 300V 10A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY127V-5.0
No of Poles : 2P,3P-24P
Pitch (mm) : 5
Rating : 300V 12A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY128VA-5.0
No of Poles : 2P,3P-24P
Pitch (mm) : 5
Rating : 300V 12A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY128VA-5.08
No of Poles : 2P,3P-24P
Pitch (mm) : 5.08
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY128RA-5.0
No of Poles : 2P,3P-24P
Pitch (mm) : 5
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY128RA-5.08
No of Poles : 2P,3P-24P
Pitch (mm) : 5.08
Rating : 300V 12A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY129VB-5.0
No of Poles : 2P,3P-24P
Pitch (mm) : 5
Rating : 300V 20A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY129VB-5.08
No of Poles : 2P,3P-24P
Pitch (mm) : 5.08
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY129RB-5.0
No of Poles : 2P,3P-24P
Pitch (mm) : 5
Rating : 300V 20A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY129RB-5.08
No of Poles : 2P,3P-24P
Pitch (mm) : 5.08
Rating : 300V 12A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY129RB-7.5
No of Poles : 2P,3P-24P
Pitch (mm) : 7.5
Rating : 300V 20A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY129RB-7.62
No of Poles : 2P,3P-24P
Pitch (mm) : 7.62
Rating : 300V 20A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY130-9.5
No of Poles : 2P,3P-24P
Pitch (mm) : 9.5
Rating : 300V 30A
Withstanding Voltage : AC3000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY300VA-5.0
No of Poles : 2P,3P-24P
Pitch (mm) : 5
Rating : 300V 10A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY301VA-5.0
No of Poles : 2P,3P-24P
Pitch (mm) : 5
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY301VB-5.08
No of Poles : 2P,3P-24P
Pitch (mm) : 5.08
Rating : 300V 10A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY302V-3.5
No of Poles : 2P,3P-24P
Pitch (mm) : 3.5
Rating : 150V 10A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY303V-3.81
No of Poles : 2P,3P-24P
Pitch (mm) : 3.81
Rating : 300V 10A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY304V-5.0
No of Poles : 2P,3P-24P
Pitch (mm) : 5
Rating : 300V 12A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY304V-5.08
No of Poles : 2P,3P-24P
Pitch (mm) : 5.08
Rating : 300V 12A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY308-2.54
No of Poles : 2P,3P-24P
Pitch (mm) : 2.54
Rating : 150V 6A
Withstanding Voltage : AC1250V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY330VA-5.0
No of Poles : 2P-24P
Pitch (mm) : 5
Rating : 300V 10A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY332-5.0
No of Poles : 2P,3P-24P
Pitch (mm) : 5
Rating : 300V 10A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XYEK381&EEK381-3.81
No of Poles : 4P-32P
Pitch (mm) : 3.81
Rating : 300V 12A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XYEK & EEK508A-5.08
No of Poles : 2*(2P,3P-24P)
Pitch (mm) : 5.08
Rating : 250V 18A
Withstanding Voltage : AC1250V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XYEK & EEK508B-5.08
No of Poles : 2*(2P,3P-24P)
Pitch (mm) : 5.08
Rating : 250V 18A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY636-6.35
No of Poles : 2P,3P-24P
Pitch (mm) : 6.35/ 7.62/ 9.52
Rating : 300V 30A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY636-7.62
No of Poles : 2P,3P-24P
Pitch (mm) : 6.35/ 7.62/ 9.52
Rating : 300V 30A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY636-9.52
No of Poles : 2P,3P-24P
Pitch (mm) : 6.35/ 7.62/ 9.52
Rating : 300V 30A
Withstanding Voltage : AC1250V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66 (UL 94V-0）

Part No : XY2500FA-5.0
No of Poles : 2P-24P
Pitch (mm) : 5
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500FB-5.08
No of Poles : 2P-24P
Pitch (mm) : 5.08
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500FAVR-5.0
No of Poles : 2P-24P
Pitch (mm) : 5.
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500FBVR-5.08
No of Poles : 2P-24P
Pitch (mm) : 5.8
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500FF-3.5
No of Poles : 2P-24P
Pitch (mm) : 3.5
Rating : 300V 8A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500FE-3.81
No of Poles : 2P-24P
Pitch (mm) : 3.81
Rating : 300V 8A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500FG-3.5
No of Poles : 2P-24P
Pitch (mm) : 3.5
Rating : 300V 8A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500FC-3.81
No of Poles : 2P-24P
Pitch (mm) : 3.81
Rating : 300V 8A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500VM-7.5
No of Poles : 2P-24P
Pitch (mm) : 7.5
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500VN-7.62
No of Poles : 2P-24P
Pitch (mm) : 7.62
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500RM-7.5
No of Poles : 2P-24P
Pitch (mm) : 7.5
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500RN-7.62
No of Poles : 2P-12P
Pitch (mm) : 7.62
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500FAV-5.08
No of Poles : 2P-24P
Pitch (mm) : 5.08
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500FBV-5.08
No of Poles : 2P-24P
Pitch (mm) : 5.08
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500RA-5.0
No of Poles : 2P-24P
Pitch (mm) : 5
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500RC-5.08
No of Poles : 2P-24P
Pitch (mm) : 5.08
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500FR-3.81
No of Poles : 2P-24P
Pitch (mm) : 3.81
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500FR-5.08
No of Poles : 2P-24P
Pitch (mm) : 5.08
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500RG-3.5
No of Poles : 2P-24P
Pitch (mm) : 3.5
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500RF-3.81
No of Poles : 2P-24P
Pitch (mm) : 3.81
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500FK-5.0
No of Poles : 2P-16P
Pitch (mm) : 5
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500FL-5.08
No of Poles : 2P-16P
Pitch (mm) : 5.08
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500FM-7.5
No of Poles : 2P-12P
Pitch (mm) : 7.5
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500FN-7.62
No of Poles : 2P-12P
Pitch (mm) : 7.62
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500RB-5.0
No of Poles : 2P-22P
Pitch (mm) : 5
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500RD-5.08
No of Poles : 2P-22P
Pitch (mm) : 5.08
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500RBS-5.0
No of Poles : 2P-22P
Pitch (mm) : 5
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500RDS-5.08
No of Poles : 2P-22P
Pitch (mm) : 5.08
Rating : 300V 15A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500VA-5.0
No of Poles : 2P-24P
Pitch (mm) : 5
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500VC-5.08
No of Poles : 2P-24P
Pitch (mm) : 5.08
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500VB-5.0
No of Poles : 2P-22P
Pitch (mm) : 5
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500VD-5.08
No of Poles : 2P-22P
Pitch (mm) : 5.08
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500VF-3.5
No of Poles : 2P-24P
Pitch (mm) : 3.5
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500VE-3.81
No of Poles : 2P-24P
Pitch (mm) : 3.81
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500VP-7.5
No of Poles : 2P-12P
Pitch (mm) : 7.5
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500VQ-7.62
No of Poles : 2P-22P
Pitch (mm) : 7.62
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500RP-7.5
No of Poles : 2P-12P
Pitch (mm) : 7.5
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY2500RQ-7.62
No of Poles : 2P-12P
Pitch (mm) : 7.62
Rating : 300V 15A
Withstanding Voltage : AC2500V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY119A-5.0
No of Poles : 1P-XXP
Pitch (mm) : 5
Rating : 300V 5A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY119B-5.08
No of Poles : 1P-XXP
Pitch (mm) : 5.08
Rating : 300V 5A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY121A-2.5
No of Poles : 1P-XXP
Pitch (mm) : 2.5
Rating : 300V 5A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY122R-5.08
No of Poles : 1P-XXP
Pitch (mm) : 5.08
Rating : 300V 10A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY122V-5.08
No of Poles : 1P-XXP
Pitch (mm) : 5.08
Rating : 300V 10A
Withstanding Voltage : AC2000V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）

Part No : XY123R-2.54
No of Poles : 1P-XXP
Pitch (mm) : 2.54
Rating : 150V 2A
Withstanding Voltage : AC1250V 60s
Operating Temperature : -40℃ ~ +105℃
Housing Material : PA66（UL 94V-0）
